A new species of rust fungi from the middle Eocene Sakhalinian amber

YURI TYKHONENKO, VERA HAYOVA, MIKHAIL IGNATOV, DMITRY VASILENKO, and EVGENY E. PERKOVSKY

Nyssopsora eocaenica Tykhonenko and Hayova sp. nov., the only fossil species of the genus Nyssopsora (Pucciniales), is described from the middle Eocene Sakhalinian amber (Russian Far East). It differs from the other known representatives of the genus by the presence of unbranched hooked appendages on the surface of teliospores. The spores are embedded in the amber sample in close proximity to a syninclusion, Heterotrissocladius naibuchi (Diptera, Chironomidae); most of them are clinged to the insect’s wing or entangled in the bristles on its legs and body. This fossil is ca. 45 myr old and provides useful information for future phylogeny-based calibration and dating of the rust fungi.

Introduction

The order Pucciniales (rust fungi) currently accommodates about 7800 species of obligate parasites of vascular plants (Kirk et al. 2008). According to the most recent phylogenetic research, rust fungi have separated from their closest relatives in Jurassic, at around 175 Ma (Aime and McTaggart 2020). Due to scarce fossil data, the time of origin of the order Pucciniales and divergence dates for its main clades were calibrated mainly by the age of the host plants and fossil evidences of other groups of fungi (McTaggart et al. 2016; Aime et al. 2018). The Nyssopsora Arthur, 1906, was established to accommodate the species with triquetrous teliospores bearing appendages on their surface (Arthur 1906). According to modern views, it belongs to the suborder Uredinineae but its taxonomic position within this taxon is not confidently resolved and the genus is not yet assigned to any family (Aime and McTaggart 2020). Currently, Nyssopsora comprises 10 species of autoecious parasites of plants of the orders Apiales and Sapindales. The present-day geographic range of the genus includes all continents except Africa and Antarctica; the centre of species diversity is located in East Asia, where six species of Nyssopsora are reported. Three of four species of Nyssopsora parasiting plants of Sapindales are confined to East and South Asia. Nyssopsora echinata reveals a prominent pattern of disjunctive distribution between Europe and western North America. In the Eocene, North Atlantic became sufficiently wide to make extremely difficult any direct migration of plants and associated obligate parasites between the continents (Milne and Abbott 2002); it therefore implies that N. echinata may have originated in the Eocene or earlier. More information on the extant species of the Nyssopsora is available in publications by Lohsomboon et al. (1990) and Carvalho Junior et al. (2014).

Over the last decade, Sakhalinian amber has yielded numerous fossil arthropods of various taxa (e.g., Simutnik 2014, 2015; Fedotova and Perkovsky 2016; Radchenko and Perkovsky 2016; Marusik et al. 2018; Dietrich and Perkovsky 2019; Kazantsev and Perkovsky 2019; Davidian et al. 2021; Perkovsky et al. 2021; Simutnik et al. 2021 and references therein). In our previous publication (Tykhonenko et al. 2021), we reported the finding of few teliospores of rust fungus similar to those of the modern species Nyssopsora trevesiae (Gäumann, 1921) Tranzschel, 1925 in a sample of Sakhalinian amber. Here we describe a new species of the fossil rust fungus from another sample of Sakhalinian amber. For information on the age, outcrop, and fossils from the Naibuchi Formation, where the specimen of Sakhalinian amber was found in situ, see Kodrul (1999).

Institutional abbreviations.—PIN, Borissiak Paleontological Institute, Moscow, Russia.

Nomenclatural acts.—This published work and the nomenclatural act it contains, have been registered in Index Fungorum: IF558769.

Material and methods

The type of Nyssopsora eocaenica Tykhonenko and Hayova sp. nov. is embedded in a small (7×4×3 mm) clear piece of amber. In the previously published article (Baranov et al. 2015), the inventory number of syninclused holotype of Heterotrissocladius naibuchi Baranov, Andersen, and Perkovsky, 2015, was erroneously indicated as PIN 3387/150; the correct number is PIN 3387/147a. Photos were taken with an Olympus CX-41 transmitted light microscope (10× and 20× lenses), with additional illumination from above with a Motic fiber optic illuminator, and an Infinity 2-2 digital camera.

The specimen PIN 3387/147 is deposited in the A.A. Boris­siak Paleontological Institute, Russian Academy of Sciences, Moscow.

Systematic palaeontology

Kingdom Fungi Moore, 1980

Division Basidiomycota Moore, 1980

Class Pucciniomycetes Bauer, Begerow, Sampaio, Weiss, and Oberwinkler, 2006

Order Pucciniales Caruel, 1881

Suborder Uredinineae Engler, 1892 emend. Aime and McTaggart, 2020

Genus Nyssopsora Arthur, 1906

Type species: Nyssopsora echinata (Léveillé, 1848) Arthur, 1906; Recent, Europe and western North America.

Nyssopsora eocaenica Tykhonenko and Hayova sp. nov.

Fig. 1.

Index Fungorum: IF558769

Etymology: Feminine adjective from Eocene, referring to its occurrence in that epoch.

Holotype: PIN 3387/147 (more than 200 detached teliospores).

Type locality: Starodubskoye village, Dolinsky District, Sakhalin Ob­last, Russia.

Type horizon: Sakhalinian amber, Naibuchi Formation, middle Eocene, 48.6–40.4 Ma.

Diagnosis.—It is easily distinguishable from other hitherto des­cribed species of the Nyssopsora by the presence of unbranched hooked appendages on the surface of teliospores.

Description.—Teliospores consist of 3 cells; the basal one is slightly larger than each of the other two which are both the apical cells. The contours resemble almost equilateral triangles with rounded corners, moderately constricted at the septa (Fig. 1). Spores are coloured, but translucent, so that the septa are clearly visible. Spore sizes vary within 33–38 × 34–37 μm. Pedicels of teliospores are not observed. The outer walls of all cells are covered with numerous simple appendages up to 6–7 μm long, hooked at the apex (Fig. 1). Host plant is unknown.

Remarks.—In the article by Baranov et al. (2015), particles adjacent to the holotype of the non-biting midge, Hetero­trisso­cladius naibuchi Bara­nov, Andersen, and Perkovsky, 2015, were considered as angiosperm pollen, but our further careful examination has revealed that undoubtedly they are teliospores of the Pucciniales fungus.

Studying of detached fungal spores is always hard because the absence of sporogenous structures and associated substrate makes correct identification extremely difficult. It is a serendipity that morphological features of the spores in the specimen PIN 3387/147 are sufficient for reliable identification of the fungus. Indeed, due to triquetrous teliospores with appendages it can be assigned to Nyssopsora with enough confidence, whereas unbranched and hooked at the tips appendages clearly distinguish the fossil from all previously described species of the extant genus. Since there are no plant inclusions in the amber sample, no reliable assumption about a host plant of Nyssopsora eocaenica Tykhonenko and Hayova sp. nov. can be made.

The left wing membrane of Heterotrissocladius naibuchi (the right wing is lost) is densely covered with setae (Baranov et al. 2015) and about 80% of all teliospores visible in the specimen PIN 3387/147 are clinged to the wing (Fig. 1A1). The position of the spores corroborates the assumption by Savile (1989) that appendages on the surface of the teliospores of rust fungi contribute to the inadvertent transfer of spores by entanglement in the bristles on the legs and body of insects.

Taxonomic identity of the Nyssopsora teliospores reported in our recent publication (Tykhonenko et al. 2021) remains unclear. PIN 3387/147 and PIN 3387/973 are both collected in the same locality and originated from the same stratigraphic horizon; however, we cannot claim conspecificity of teliospores in PIN 3387/147 and PIN 3387/973 due to a small number of spores in the latter and due to a rather uncertain morphology of their appendages.

Stratigraphic and geographic range.—Type locality and horizon only.

Concluding remarks

The age of the amber sample containing Nyssopsora eocaenica Tykhonenko and Hayova sp. nov. is reliably determined as ca. 43–47 Ma (Radchenko and Perkovsky 2016). It indica­tes that Nyssopsora must have originated before that time, which is in concordance with current estimation of age (53–83 Ma) for the most recent common ancestor of Nyssopsora, Sphaerophragmiaceae and Pucciniaceae (Aime and McTaggart 2020). Thus information on this newly described middle Eocene-aged species of rust fungi can provide some evidence and contribute to estimation of divergence times for the clades of the suborder Uredinineae and the order Pucciniales as a whole in future phylogenetic analyses.

Acknowledgements.—We greatly thank Alexandr Rasnitsyn and Irina Sukacheva (both PIN) for the possibility to study Sakhalinian amber inclusions. Useful comments on the manuscript of Alistair McTaggart (The University of Queensland, Brisbane, Australia) and of two anonymous reviewers are much appreciated and were gratefully accepted in the final version. Ministry of Higher Education and Science of Russian Federation is thanked for the support provided to the Center of Collective Use “Herbarium MBG RAS” Grant 075-15-2021-678.

References

Aime, M.C., Bell, C.D., and Wilson, A.W. 2018. Deconstructing the evolutionary complexity between rust fungi (Pucciniales) and their plant hosts. Studies in Mycology 89: 143–152. Crossref

Aime, M.C. and McTaggart, A.R. 2020. A higher-rank classification for rust fungi, with notes on genera. Fungal Systematics and Evolution 7: 21–47. Crossref

Arthur, J.C. 1906. Eine auf die Struktur und Entwicklungsgeschichte begründete Klassifikation der Uredineen. In: J.P. Lotsy (ed.), Résultats Scientifiques Du Congrès International De Botanique, Vienne (1905), 331–348. Verlag von Gustav Fischer, Jena.

Baranov, V., Andersen, T., and Perkovsky, E.E. 2015. Orthoclads from Eocene amber from Sakhalin (Diptera: Chironomidae, Orthocladiinae). Insect Systematics & Evolution 46: 359–378. Crossref

Bauer, R., Begerow, D., Sampaio, J.P., Weiss, M., and Oberwinkler, F. 2006. The simple-septate basidiomycetes: a synopsis. Mycological Progress 5: 41–66. Crossref

Caruel, T. 1881. Pensieri sulla tassinomia botanica. Atti della Reale Accademia dei Lincei, Memorie della Classe di Scienze Fisiche, Matematiche e Naturali Ser. 3 10: 161–251.

Carvalho Junior, A.A., Esquivel Rios, E., and Piepenbring, M. 2014. A new species of Nyssopsora (Pucciniales) from Panama. Nova Hedwigia 99: 65–70. Crossref

Davidian, E.M., Kaliuzhna, M.O., and Perkovsky, E.E. 2021. First aphidiine wasp from the Sakhalinian amber. Acta Palaeontologica Polonica 66 (Supplement to 3): S59–S65. Crossref

Dietrich, C.H. and Perkovsky, E.E. 2019. First record of Cicadellidae (Insecta: Hemiptera: Auchenorrhyncha) from Eocene Sakhalinian amber. ZooKeys 886: 127–134. Crossref

Engler, A. 1892. Syllabus der Vorlesungen über spezielle und medizinisch-pharmazeutische Botanik. 230 pp. Gebrüder Borntraeger Verlagsbuchhandlung, Berlin.

Fedotova, Z.A. and Perkovsky, E.E. 2016. A new genus and species of gall midges of the supertribe Heteropezidi (Diptera, Cecidomyiidae) found in Eocene amber from Sakhalin. Paleontological Journal 50: 1033–1037. Crossref

Gäumann, E. 1921 Mycologische Mitteilungen I. Bulletin du Jardin Bota­nique de Buitenzorg 3 (2): 121–127.

Kazantsev, S.V. and Perkovsky, E.E. 2019. A new genus of soldier beetles (Insecta: Coleoptera: Cantharidae: Cantharinae) from Sakhalinian amber. Paleontological Journal 53: 300–304. Crossref

Kirk, P.M., Cannon, P.F., Minter, D.W., and Stalpers, J.A. 2008. Ainsworth & Bisby’s Dictionary of the Fungi. 10th Edition. 771 рр. CAB International, Wallingford. Crossref

Kodrul, T.M. 1999. Paleogene phytostratigraphy of the South Sakhalin [in Russian]. Trudy Geologičeskogo Instituta Rossijskoj Akademii Nauk 519: 1–150.

Léveillé, J.H. 1848. Fragments mycologiques. Annales des Sciences Naturelles Botanique 9: 245–262.

Lohsomboon, P., Kakishima, M., and Ono, Y. 1990. A revision of the genus Nyssopsora (Uredinales). Mycological Research 94: 907–922. Crossref

Marusik, Y.M., Perkovsky, E.E., and Eskov, K.Y. 2018. First records of spiders (Arachnida: Aranei) from Sakhalinian amber with description of a new species of the genus Orchestina Simon, 1890. Far Eastern Entomologist 367: 1–9. Crossref

McTaggart, A.R., Shivas, R.G., van der Nest, M.A., Roux, J., Wingfield, B.D., and Wingfield, M.J. 2016. Host jumps shaped the diversity of extant rust fungi (Pucciniales). New Phytologist 209: 1149–1158. Crossref

Milne, R.I. and Abbott, R.J. 2002. The origin and evolution of Tertiary relict floras. Advances in Botanical Research 38: 281–314. Crossref

Moore, R.T. 1980. Taxonomic proposals for the classification of marine yeasts and other yeast-like fungi including the smuts. Botanica Marina 23: 361–373.

Perkovsky, E.E., Háva, J. and Zaitsev, A.A. 2021. The first finding of a skin beetle (Coleoptera, Dermestidae) from Sakhalinian amber. Paleontological Journal 55: 184–192. Crossref

Radchenko, A.G. and Perkovsky, E.E. 2016. The ant Aphaenogaster dlus­skyana sp. nov. (Hymenoptera, Formicidae) from the Sakhalin amber—the earliest described species of an extant genus of Myrmicinae. Paleontological Journal 50: 936–946. Crossref

Savile, D.B.O. 1989. Raveneliaceae revisited. Canadian Journal of Botany 67: 2983–2994. Crossref

Simutnik, S.A. 2014. The first record of Encyrtidae (Hymenoptera, Chalcidoidea) from the Sakhalin amber. Paleontological Journal 48: 621–623. Crossref

Simutnik, S.A. 2015. Description of two new monotypical genera of encyrtid wasps (Hymenoptera, Chalcidoidea: Encyrtidae), based on males from the middle Eocene Sakhalin amber. Entomological Review 95: 937–940. Crossref

Simutnik, S.A., Perkovsky, E.E., and Vasilenko, D.V. 2021. Sakhalinencyrtus leleji Simutnik gen. et sp. nov. of earliest Encyrtidae (Hymenoptera, Chalcidoidea) from Sakhalinian amber. In: M.Y. Proshchalykin and V.E. Gokhman (eds.), Hymenoptera studies through space and time: A collection of papers dedicated to the 75th anniversary of Ar­kady S. Lelej. Journal of Hymenoptera Research 84: 361–372. Crossref

Tranzschel, V.A. [Tranšel’, V.A.] 1925. Systematics and biology of the genus Triphragmium auct (Triphragmium Link, Triphragmiopsis Naumov, Nyssopsora Arthur) [in Russian]. Žurnal Botaničeskogo obŝestva Rossii 8: 123–132.

Tykhonenko, Y.Y., Hayova, V.P., Sukhomlyn, M.N., Ignatov, M.S., Vasi­lenko, D.V., and Perkovsky, E.E. 2021. The first record of the rust fungus (Pucciniales) spores from middle Eocene Sakhalinian amber. Paleontological Journal 55: 105–110. Crossref

Yuri Tykhonenko [yu.ya.tykhonenko@gmail.com; ORCID: https://orcid.org/0000-0001-9000-7406] and Vera Hayova [v.hayova@gmail.com, https://orcid.org/0000-0002-7038-1633] (corresponding author); Kholodny Institute of Botany, National Academy of Sciences of Ukraine, 2 Tereshchenkivska Str., Kyiv, 01601, Ukraine.

Mikhail Ignatov [misha_ignatov@list.ru; ORCID: https://orcid.org/0000-0001-6096-6315], Tsytsin Main Moscow Botanical Garden of Academy of Sciences, Russian Academy of Sciences, 4 Botanicheskaya Str., Moscow,127276, Russia.

Dmitry Vasilenko [damageplant@mail.ru], Borissiak Paleontological Institute, Russian Academy of Sciences, 123 Profsoyuznaya Str, Moscow, 117647, Russia and Cherepovets State University, Lunacharsky Avenue, 5, Cherepovets, 162600, Russia.

Evgeny E. Perkovsky [perkovsk@gmail.com; ORCID: https://orcid.org/0000-0002-7959-4379], Schmalhausen Institute of Zoology, National Academy of Sciences of Ukraine, 15 Bogdan Khmelnitski Str., Kyiv, 01601, Ukraine.

Received 13 June 2021, accepted 13 September 2021, available online 19 November 2021.

Copyright © 2021 Y. Tykhonenko et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License (for details please see http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

Acta Palaeontol. Pol. 66 (4): 921–924, 2021

https://doi.org/10.4202/app.00917.2021
